ACT TA1-XTG6 – 1995 Toyota Tacoma XT/Race Sprung 6 Pad Clutch Kit

Description

ACT TA1-XTG6 – 1995 Toyota Tacoma XT/Race Sprung 6 Pad Clutch Kit

ACT Extreme Off-Road Race Sprung 6 Pad Clutch Kit

XT-O/Race Sprung 6 Pad

TA1-XTG6 kit features ACT’s powerful Xtreme pressure plate and spring center 4 pad race disc delivering ultra-high torque capacity, aggressive engagement, quiet operation and increased toughness to withstand the demands of off-road racing. ACT’s exclusive diaphragm design dramatically increases clamp load, reduces deflection and maximizes clutch life. All diaphragms endure a four-stage heat-treating process for unparalleled performance. ACT precision pressure plate cover stampings provide rigidity and consistency while precision machined pressure plate castings absorb heat. ACT’s spring center 4 pad race discs boast quality parts throughout, with robust spring center sections to absorb driveline shock and premium ceramic friction materials to hold power even under the most abusive conditions.

• “Excellence in Performance”, backed by the best one-year warranty in the industry!

Product Weight (lbs.): 17.3Torque Capacity (ft/lbs.): 450Torque Capacity Over OE: 107%Pilot Bushing Included: NoPressure Plate Type: XtremeRelease Bearing Included: YesClutch Disc Diameter: 9.3Clutch Disc Diameter: 236Disc Material: CeramicInput Spline Quantity: 21Input Shaft Diameter: 1.125Alignment Tool Included: YesDisc Type Sprung Solid: SprungPressure Plate Bolts Included: NoGrease Included: YesGrade Type: PerformanceClutch Slave Cylinder Included: NoFlywheel Bolts Included: NoPilot Bearing Included: YesClutch Master Cylinder Included: No
